NZ2520SA-2.750000MHZ
lmages are for reference only.NZ2520SA-2.750000MHZ
XTAL OSC TCXO 2.7500MHZ CMOS SMD
Datasheet4-SMD, No Lead
70,354 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.75 MHz TCXO CMOS Oscillator 3V Standby (Power Down) 4-SMD, No Lead
NZ2520SA-2.750000MHZ
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | NDK America, Inc. |
| Series | NZ2520SA |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 2.75 MHz |
| Function | Standby (Power Down) |
| Output | CMOS |
| Voltage - Supply | 3V |
| Frequency Stability | ±30ppm |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -10°C ~ 60°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 5mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Height - Seated (Max) | 0.035" (0.90mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | NZ2520SA-20.000000MHZ | NZ2520SA-22.000000MHZ | NZ2520SA-25.600MHZ | NZ2520SA-10.000000MHZ |
| Manufacturer | NDK America, Inc. | NDK America, Inc. | NDK America, Inc. | NDK America, Inc. |
| RoHS Status | ||||
| Description | XTAL OSC TCXO 20.0000MHZ CMOS | XTAL OSC TCXO 22.0000MHZ CMOS | XTAL OSC TCXO 25.6000MHZ CMOS | XTAL OSC TCXO 10.0000MHZ CMOS |
| Series | NDK America, Inc. | NDK America, Inc. | NDK America, Inc. | NDK America, Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
