O 26,0-JT21ETE-A-K-3,3-LF
lmages are for reference only.O 26,0-JT21ETE-A-K-3,3-LF
OSC TCXO 26MHZ 3.3V CLPSNWV SMD
Datasheet4-SMD, No Lead
18,224 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
26 MHz TCXO Clipped Sine Wave Oscillator 3.3V Enable/Disable 4-SMD, No Lead
O 26,0-JT21ETE-A-K-3,3-LF
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | Jauch Quartz |
| Series | JT21ETE |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 26 MHz |
| Function | Enable/Disable |
| Output | Clipped Sine Wave |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±2.5ppm |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 1.5mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Height - Seated (Max) | 0.031" (0.80mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | O 26,0-JT21CT-A-P-1,8-LF | O 26,0-JT21CT-A-P-3,3-LF | O 26,0-JT21G-E-K-1,8-LF | O 26,0-JT21G-E-K-3,3-LF |
| Manufacturer | Jauch Quartz | Jauch Quartz | Jauch Quartz | Jauch Quartz |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OSC TCXO 26MHZ 1.8V HCMOS SMD | OSC TCXO 26MHZ 3.3V HCMOS SMD | OSC TCXO 26MHZ 1.8V SNWV | OSC TCXO 26MHZ 3.3V SNWV |
| Series | Jauch Quartz | Jauch Quartz | Jauch Quartz | Jauch Quartz |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
