OWIHP0420M-6R8
lmages are for reference only.OWIHP0420M-6R8
FIXED IND 6.8UH 2.5A 175 MOHM SM
DatasheetNonstandard
89,278 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
6.8 µH Unshielded Molded Inductor 2.4 A 175mOhm Nonstandard
OWIHP0420M-6R8
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Ole Wolff Electronics Inc |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Molded |
| Material - Core | Carbonyl Powder |
| Inductance | 6.8 µH |
| Tolerance | - |
| Current Rating (Amps) | 2.4 A |
| Current - Saturation (Isat) | 2.5A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 175mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | - |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.173" L x 0.165" W (4.40mm x 4.20mm) |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | OWIHP0420M-1R0 | OWIHP0420M-1R5 | OWIHP0420M-3R3 | OWIHP0420M-4R7 |
| Manufacturer | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 1UH 7A 27 MOHM SMD | FIXED IND 1.5UH 5.5A 46 MOHM SMD | FIXED IND 3.3UH 3.5A 87 MOHM SMD | FIXED IND 4.7UH 3A 105 MOHM SMD |
| Series | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc | Ole Wolff Electronics Inc |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
