P4KE36-E3/54
lmages are for reference only.P4KE36-E3/54
TVS DIODE 29.1VWM 52VC DO204AL
DatasheetDO-204AL, DO-41, Axial
34,461 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
52V Clamp 7.7A Ipp Tvs Diode Through Hole DO-204AL (DO-41)
P4KE36-E3/54
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | TransZorb® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 29.1V |
| Voltage - Breakdown (Min) | 32.4V |
| Voltage - Clamping (Max) @ Ipp | 52V |
| Current - Peak Pulse (10/1000µs) | 7.7A |
| Power - Peak Pulse | 400W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) |
| Base Product Number | P4KE36 |
| Unidirectional Channels | 1 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | P4KE36 | P4KE36 | P4KE36-B | P4KE36A |
| Manufacturer | Littelfuse Inc. | Taiwan Semiconductor Corporation | Littelfuse Inc. | SMC Diode Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | TVS DO15 29.1V 400W UNIDIR | 400W, 36V, UNIDIRECTIONAL, TVS | TVS DIODE 30.8VWM 52.4VC DO204AL | TVS DIODE 29.1VWM 49.9VC DO41 |
| Series | Littelfuse Inc. | Taiwan Semiconductor Corporation | Littelfuse Inc. | SMC Diode Solutions |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Bulk | Tape & Reel (TR) |
