Optoisolator Transistor Output 5000Vrms 1 Channel 4-SMD
PC852XNNIP1H
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | SHARP/Socle Technology |
| Series | PC852X |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Current Transfer Ratio (Min) | 1000% @ 1mA |
| Current Transfer Ratio (Max) | 15000% @ 1mA |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 100µs, 20µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 350V |
| Current - Output / Channel | 150mA |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50 mA |
| Vce Saturation (Max) | 1.2V |
| Operating Temperature | -30°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, Gull Wing |
| Supplier Device Package | 4-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | PC852XNNIP0F | PC852X | PC852XI | PC852XIJ000F |
| Manufacturer | SHARP/Socle Technology | Sharp Microelectronics | Sharp Microelectronics | Sharp Microelectronics |
| RoHS Status | RoHS Compliant | RoHS non-compliant | RoHS non-compliant | |
| Description | OPTOISOLATOR 5KV DARL 4SMD | OPTOISOLATOR 5KV DARL 4DIP | OPTOISOLATOR 5KV DARL 4SMD | OPTOISOLATOR 5KV DARL 4SMD |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Tube | Tube |
