Product CatalogPart Number
PCN13-16S-2.54DS(71)
Manufacturer
Hirose Electric Co LtdDescription
CONN DIN RCPT 16POS PCB RA GOLD
Datasheet
DatasheetPackage
-
In Stock
86,552 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PCN13-16S-2.54DS(71)
PCN13-16S-2.54DS(71)
lmages are for reference only.Payment Methods
Delivery Services
16 Position Din Connector Receptacle, Female Sockets Gold Through Hole, Right Angle
Quick Inquiry
PCN13-16S-2.54DS(71)
Specifications
| Category | Connectors, Interconnects - Backplane Connectors - DIN 41612 |
| Manufacturer | Hirose Electric Co Ltd |
| Series | PCN13 |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 16 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Style | - |
| Level, Class | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 3.94µin (0.10µm) |
| Operating Temperature | -55°C ~ 85°C |
| Current Rating (Amps) | 2A |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Base Product Number | PCN13 |
