PDTD114EQAZ
lmages are for reference only.PDTD114EQAZ
TRANS PREBIAS NPN 50V 0.5A 3DFN
Datasheet3-XDFN Exposed Pad
36,437 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased 50 V 500 mA 210 MHz 325 mW Surface Mount DFN1010D-3
PDTD114EQAZ
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Nexperia USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 500 mA |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
| Resistor - Base (R1) | 10 kOhms |
| Resistor - Emitter Base (R2) | 10 kOhms |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 70 @ 50mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 100mV @ 2.5mA, 50mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | 210 MHz |
| Power - Max | 325 mW |
| Mounting Type | Surface Mount |
| Package / Case | 3-XDFN Exposed Pad |
| Supplier Device Package | DFN1010D-3 |
| Base Product Number | PDTD114 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute | |
 |
 |
|
| Part Number | PDTD114EQAZ | PDTD114ETR | PDTD114ETVL | PDTD114EU-QX |
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | TRANS PREBIAS | TRANS PREBIAS NPN 50V TO236AB | TRANS PREBIAS NPN 50V TO236AB | PDTD114EU-Q/SOT323/SC-70 |
| Series | * | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
