PE29102A-X
Manufacturer
pSemiDescription
IC GATE DRVR HALF-BRIDGE DIE
Datasheet
DatasheetPackage
Die
In Stock
58,927 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PE29102A-X
PE29102A-X
lmages are for reference only.Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Inverting Die
Quick Inquiry
PE29102A-X
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | pSemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4V ~ 6V |
| Logic Voltage - VIL, VIH | 0.6V, 1.6V |
| Current - Peak Output (Source, Sink) | 2A, 4A |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 100 V |
| Rise / Fall Time (Typ) | 900ps, 900ps |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | Die |
| Supplier Device Package | Die |
| Base Product Number | PE29102 |
| Grade | - |
| Qualification | - |
