PESD48VV2BTR
lmages are for reference only.PESD48VV2BTR
PESD48VV2BT/SOT23/TO-236AB
DatasheetTO-236-3, SC-59, SOT-23-3
96,544 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
67V Clamp 3.5A (8/20µs) Ipp Tvs Diode Surface Mount TO-236AB
PESD48VV2BTR
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Nexperia USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 48V (Max) |
| Voltage - Breakdown (Min) | 56V |
| Voltage - Clamping (Max) @ Ipp | 67V |
| Current - Peak Pulse (10/1000µs) | 3.5A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | USB |
| Capacitance @ Frequency | 7.1pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | TO-236AB |
| Base Product Number | PESD48 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | PE13SD03M4Q_R1_00201 | PE1403M1Q_R1_00001 | PE1403M1Q_R1_00501 | PE1403M2Q_R1_00001 |
| Manufacturer | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 3.3V,ESD,DFN2510A-10L,UNI | ULTRA LOW CAPACITANCE ESD PROTEC | 3.3V,ESD PROTECTION,DFN1006-2L,U | ULTRA LOW CAPACITANCE ESD PROTEC |
| Series | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
