PIP201-12M-3,518
lmages are for reference only.PIP201-12M-3,518
IC HALF BRIDGE DRVR 20A 68HVQFN
Datasheet68-VFQFN Exposed Pad
64,881 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge Driver Synchronous Buck Converters Power MOSFET 68-HVQFN (10x10)
PIP201-12M-3,518
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Half Bridge |
| Applications | Synchronous Buck Converters |
| Interface | PWM |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | - |
| Current - Output / Channel | 20A |
| Current - Peak Output | 200A |
| Voltage - Supply | 12V |
| Voltage - Load | 25V (Max) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Features | Bootstrap Circuit |
| Fault Protection | - |
| Mounting Type | Surface Mount |
| Package / Case | 68-VFQFN Exposed Pad |
| Supplier Device Package | 68-HVQFN (10x10) |
| Base Product Number | PIP201 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | PIP201-12M-3,518 | PWD5F60TR | PT80C525-VC-B | PWD5F60 |
| Manufacturer | NXP USA Inc. | STMicroelectronics | National Semiconductor | STMicroelectronics |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | Not applicable | ROHS3 Compliant |
| Description | IC HALF BRIDGE DRVR 20A 68HVQFN | IC HALF BRIDGE DRV 3.5A 46VFQFPN | PICO POWER PRODUCT, PCI TO PCI B | IC HALF BRIDGE DRV 3.5A 46VFQFPN |
| Series | - | - | * | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tray |
