PJQ5465A-AU_R2_000A1
lmages are for reference only.PJQ5465A-AU_R2_000A1
60V P-CHANNEL ENHANCEMENT MODE M
Datasheet8-PowerVDFN
30,588 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 60 V 5A (Ta), 16A (Tc) 2W (Ta), 25W (Tc) Surface Mount DFN5060-8
PJQ5465A-AU_R2_000A1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Panjit International Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 5A (Ta), 16A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 48mOhm @ 8A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1256 pF @ 30 V |
| FET Feature | - |
| Power Dissipation (Max) | 2W (Ta), 25W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DFN5060-8 |
| Package / Case | 8-PowerVDFN |
| Base Product Number | PJQ5465 |
| Gate Charge (Qg) (Max) @ Vgs | 22 nC @ 10 V |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
|
 |
| Part Number | PJQ5410_R2_00001 | PJQ5411_R2_00001 | PJQ5412_R2_00001 | PJQ5413_R2_00001 |
| Manufacturer | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. | Panjit International Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 30V N-CHANNEL ENHANCEMENT MODE M | 30V P-CHANNEL ENHANCEMENT MODE M | 30V N-CHANNEL ENHANCEMENT MODE M | 30V P-CHANNEL ENHANCEMENT MODE M |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
