Product CatalogPart Number
PM610-05-B
Manufacturer
Bourns Inc.Description
INDUCT ARRAY 6 COIL 11.6UH SMD
Datasheet
DatasheetPackage
12-SMD, Gull Wing
In Stock
76,122 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PM610-05-B
PM610-05-B
lmages are for reference only.Payment Methods
Delivery Services
Unshielded 6 Coil Inductor Array 417.6 µH Inductance - Connected in Series 11.6 µH Inductance - Connected in Parallel 34mOhm DC Resistance (DCR) - Parallel 4.08 A 12-SMD, Gull Wing
Quick Inquiry
PM610-05-B
Specifications
| Category | Inductors, Coils, Chokes - Arrays-Signal Transformers - |
| Manufacturer | Bourns Inc. |
| Series | PM610 |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Number of Coils | 6 |
| Inductance - Connected In Parallel | 11.6 µH |
| Inductance - Connected In Series | 417.6 µH |
| Tolerance | ±10% |
| Current Rating - Parallel | 4.08 A |
| Current Rating - Series | 680 mA |
| Current Saturation - Parallel | 7.8 A |
| Current Saturation - Series | 1.3 A |
| DC Resistance (DCR) - Parallel | 34mOhm |
| DC Resistance (DCR) - Series | 1.212Ohm |
| Shielding | Unshielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 12-SMD, Gull Wing |
| Size / Dimension | 0.591" L x 0.630" W (15.00mm x 16.00mm) |
| Height | 0.307" (7.80mm) |
| Base Product Number | PM610 |
Parts with Similar Specifications
| Product Attribute | |
 |
|
|
| Part Number | PM610-05-B | PM610-05-RC | PM610-05-RC | PM610-01-RC |
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | INDUCT ARRAY 6 COIL 11.6UH SMD | INDUCT ARRAY 6 COIL 11.6UH SMD | INDUCT ARRAY 6 COIL 11.6UH SMD | INDUCT ARRAY 6 COIL 160UH SMD |
| Series | PM610 | PM610 | PM610 | PM610 |
| Packaging | Bulk | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
