PMN34LN,135
Manufacturer
NXP USA Inc.Description
MOSFET N-CH 20V 5.7A 6TSOP
Datasheet
DatasheetPackage
SC-74, SOT-457
In Stock
41,150 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PMN34LN,135
PMN34LN,135
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 20 V 5.7A (Tc) 1.75W (Tc) Surface Mount SC-74
Quick Inquiry
PMN34LN,135
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | NXP USA Inc. |
| Series | TrenchMOS™ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 5.7A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 34mOhm @ 2.5A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Vgs (Max) | ±15V |
| Input Capacitance (Ciss) (Max) @ Vds | 500 pF @ 20 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.75W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SC-74 |
| Package / Case | SC-74, SOT-457 |
| Base Product Number | PMN3 |
| Gate Charge (Qg) (Max) @ Vgs | 13.1 nC @ 10 V |
| Grade | - |
| Qualification | - |
