PQ1CZ38M2ZZ
lmages are for reference only.PQ1CZ38M2ZZ
IC REG BUCK ADJ 800MA SC63
DatasheetTO-252-6, DPAK (5 Leads + Tab)
91,399 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Switching Regulator IC Positive or Negative Adjustable ±1.26V 1 Output 800mA TO-252-6, DPAK (5 Leads + Tab)
PQ1CZ38M2ZZ
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Sharp Microelectronics |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Function | Step-Down |
| Output Configuration | Positive or Negative |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 8V |
| Voltage - Input (Max) | 35V |
| Voltage - Output (Min/Fixed) | ±1.26V |
| Voltage - Output (Max) | 35V, -30V |
| Current - Output | 800mA |
| Frequency - Switching | 300kHz |
| Synchronous Rectifier | No |
| Operating Temperature | -20°C ~ 80°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-6, DPAK (5 Leads + Tab) |
| Supplier Device Package | SC-63 |
| Base Product Number | PQ1CZ38 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | PQ1CZ38M2ZZH | PQ1CZ21H2ZPH | PQ1CZ21H2ZZ | PQ1CZ21H2ZZH |
| Manufacturer | Sharp Microelectronics | Sharp Microelectronics | Sharp Microelectronics | Sharp Microelectronics |
| RoHS Status | RoHS non-compliant | |||
| Description | IC REG BUCK ADJ 800MA SC63 | IC REG BUCK ADJ 1.5A SC63 | IC REG BUCK ADJ 1.5A SC63 | IC REG BUCK ADJ 1.5A SC63 |
| Series | Sharp Microelectronics | Sharp Microelectronics | Sharp Microelectronics | Sharp Microelectronics |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tube |
