PQ2613-1R0-80-G
lmages are for reference only.PQ2613-1R0-80-G
FIXED IND 1UH 80A 1.2 MOHM SMD
DatasheetNonstandard
77,150 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 µH Unshielded Planar Inductor 80 A 1.2mOhm Nonstandard
PQ2613-1R0-80-G
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Standex-Meder Electronics |
| Series | PQ |
| Packaging | Bulk |
| RoHS Status | |
| Type | Planar |
| Material - Core | Ferrite |
| Inductance | 1 µH |
| Tolerance | - |
| Current Rating (Amps) | 80 A |
| Current - Saturation (Isat) | 120A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 1.2mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -30°C ~ 125°C |
| Inductance Frequency - Test | - |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 1.043" L x 0.748" W (26.50mm x 19.00mm) |
| Height - Seated (Max) | 0.520" (13.20mm) |
| Base Product Number | - |
| Product Attribute | |
 |
 |
 |
| Part Number | PQ2613-1R0-80-G | PQ2614BHA-100K | PQ2614BHA-150K | PQ2614BHA-220K |
| Manufacturer | Standex-Meder Electronics | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | FIXED IND 1UH 80A 1.2 MOHM SMD | FIXED IND 10UH 30A 1.9 MOHM SMD | FIXED IND 15UH 30A 1.9 MOHM SMD | FIXED IND 22UH 30A 1.9 MOHM SMD |
| Series | Standex-Meder Electronics | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Packaging | Bulk | Tray | Tray | Tray |
