PS9313L2-AX
Manufacturer
CELDescription
OPTOISO 5KV OPEN COLL 6DIP GW
Datasheet
DatasheetPackage
6-SOIC (0.268", 6.80mm Width)
In Stock
19,609 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PS9313L2-AX
PS9313L2-AX
lmages are for reference only.Payment Methods
Delivery Services
Logic Output Optoisolator 1Mbps Open Collector 5000Vrms 1 Channel 15kV/µs CMTI 6-SDIP Gull Wing
Quick Inquiry
PS9313L2-AX
Specifications
| Category | Isolators - Optoisolators - Logic Output Optoisolators |
| Manufacturer | CEL |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 15kV/µs |
| Input Type | DC |
| Output Type | Open Collector |
| Current - Output / Channel | 15 mA |
| Data Rate | 1Mbps |
| Propagation Delay tpLH / tpHL (Max) | 750ns, 500ns |
| Rise / Fall Time (Typ) | - |
| Voltage - Forward (Vf) (Typ) | 1.56V |
| Current - DC Forward (If) (Max) | 25mA |
| Voltage - Supply | 4.5V ~ 20V |
| Operating Temperature | -40°C ~ 110°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SOIC (0.268", 6.80mm Width) |
| Supplier Device Package | 6-SDIP Gull Wing |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
