N-Channel 100 V 120A (Tc) 338W (Tc) Through Hole TO-220AB
PSMN5R0-100PS,127
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 120A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 5mOhm @ 25A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 9900 pF @ 50 V |
| FET Feature | - |
| Power Dissipation (Max) | 338W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220AB |
| Package / Case | TO-220-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 170 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | PSMN5R0-100ES,127 | PSMN5R0-100PS,127 | PSMN5R0-100XS,127 | PSMN5R0-30YL,115 |
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | NXP USA Inc. | Nexperia USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 100V 120A I2PAK | MOSFET N-CH 100V 120A TO220AB | MOSFET N-CH 100V 67.5A TO220F | MOSFET N-CH 30V 91A LFPAK56 |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
