PTH03020WAH
lmages are for reference only.PTH03020WAH
DC DC CONVERTER 0.8-2.5V 55W
Datasheet10-DIP Module
13,626 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 2.5V 22A 2.95V - 3.65V Input
PTH03020WAH
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | PTH03020W (55W) |
| Packaging | Tray |
| RoHS Status | |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.95V |
| Voltage - Input (Max) | 3.65V |
| Voltage - Output 1 | 0.8 ~ 2.5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 22A |
| Power (Watts) | 55 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OTP, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 93% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 10-DIP Module |
| Size / Dimension | 1.50" L x 0.87" W x 0.35" H (38.1mm x 22.1mm x 8.9mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | - |
| Product Attribute |  |
|
 |
|
| Part Number | PTH03020WAD | PTH03020WAH | PTH03020WAS | PTH03020WAS |
| Manufacturer | ARTESYN / Advanced Energy | Texas Instruments | ARTESYN / Advanced Energy | Texas Instruments |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DC DC CONVERTER 0.8-2.5V 55W | DC DC CONVERTER 0.8-2.5V 22A | DC DC CONVERTER 0.8-2.5V 55W | DC DC CONVERTER 0.8-2.5V 55W |
| Series | ARTESYN / Advanced Energy | Texas Instruments | ARTESYN / Advanced Energy | Texas Instruments |
| Packaging | Tray | Tray | Tray | Tray |
