PTH05030WAZT
lmages are for reference only.PTH05030WAZT
DC DC CONVERTER 0.8-3.6V 108W
Datasheet13-SMD Module
55,422 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.6V 30A 4.5V - 5.5V Input
PTH05030WAZT
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | PTH05030 (108W) |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output 1 | 0.8 ~ 3.6V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 30A |
| Power (Watts) | 108 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OTP, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 94% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 13-SMD Module |
| Size / Dimension | 1.37" L x 1.12" W x 0.35" H (34.8mm x 28.5mm x 9.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | PTH05030 |
| Voltage - Isolation | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | PTH05030WAZ | PTH05030WAZ | PTH05030WAZT | PTH05030WAD |
| Manufacturer | Texas Instruments | ARTESYN / Advanced Energy | Texas Instruments | ARTESYN / Advanced Energy |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | DC DC CONVERTER 0.8-3.6V 108W | CONV DC/DC 5VIN ADJ OUT 30A SMD | DC DC CONVERTER 0.8-3.6V 108W | DC DC CONVERTER 0.8-3.6V 108W |
| Series | Texas Instruments | ARTESYN / Advanced Energy | Texas Instruments | ARTESYN / Advanced Energy |
| Packaging | Tray | Tray | Tape & Reel (TR) | Tray |
