PTH12010WAZ
lmages are for reference only.PTH12010WAZ
DC DC CONVERTER 1.2-5.5V 66W
Datasheet10-SMD Module
83,425 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 1.2 ~ 5.5V 12A 10.8V - 13.2V Input
PTH12010WAZ
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | PTH12010 (66W) |
| Packaging | Tray |
| RoHS Status | RoHS Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 10.8V |
| Voltage - Input (Max) | 13.2V |
| Voltage - Output 1 | 1.2 ~ 5.5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 12A |
| Power (Watts) | 66 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 94% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD Module |
| Size / Dimension | 1.37" L x 0.62" W x 0.35" H (34.8mm x 15.7mm x 8.9mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | PTH12010 |
| Voltage - Isolation | - |
| Product Attribute |  |
 |
|
|
| Part Number | PTH12010WAD | PTH12010WAH | PTH12010WAH | PTH12010WAH |
| Manufacturer | ARTESYN / Advanced Energy | ARTESYN / Advanced Energy | Texas Instruments | Texas Instruments |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DC DC CONVERTER 1.2-5.5V 66W | DC DC CONVERTER 1.2-5.5V 66W | DC DC CONVERTER 1.2-5.5V 12A | DC DC CONVERTER 1.2-5.5V 12A |
| Series | ARTESYN / Advanced Energy | ARTESYN / Advanced Energy | Texas Instruments | Texas Instruments |
| Packaging | Tray | Tray | Tray | Tray |
