PVI5013RPBF
lmages are for reference only.PVI5013RPBF
OPTOELECTRONIC DEVICE
Datasheet8-DIP (0.300", 7.62mm)
19,761 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Photovoltaic Output 3750Vrms 2 Channel 8-DIP
PVI5013RPBF
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | International Rectifier |
| Series | PVI |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Number of Channels | 2 |
| Voltage - Isolation | 3750Vrms |
| Current Transfer Ratio (Min) | - |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | 5ms, 250µs (Max) |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Photovoltaic |
| Voltage - Output (Max) | 8V |
| Current - Output / Channel | 1µA |
| Voltage - Forward (Vf) (Typ) | - |
| Current - DC Forward (If) (Max) | - |
| Vce Saturation (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-DIP |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | PVI5013RPBF | PVI5013R | PVI5013RS | PVI5013RS-TPBF |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | OPTOISO 3.75KV 2CH PHVOLT 8-DIP | OPTOISO 3.75KV 2CH PHVOLT 8-DIP | OPTOISO 3.75KV 2CH PHVOLT 8-SMT | OPTOISO 3.75KV 2CH PHVOLT 8-SMT |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR) |
