PVN012PBF
lmages are for reference only.PVN012PBF
PVN012 - PHOTOVOLTAIC RELAY
Datasheet6-DIP (0.300", 7.62mm)
25,360 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Solid State SPST-NO (1 Form A) 6-DIP (0.300", 7.62mm)
PVN012PBF
| Category | Relays - Solid State Relays SSR - |
| Manufacturer | International Rectifier |
| Series | PVN, HEXFET® |
| Packaging | Bulk |
| RoHS Status | |
| Mounting Type | Through Hole |
| Circuit | SPST-NO (1 Form A) |
| Output Type | AC, DC |
| Voltage - Input | 1.2VDC |
| Voltage - Load | 0 V ~ 20 V |
| Load Current | 2.5 A |
| Termination Style | PC Pin |
| Operating Temperature | - |
| Package / Case | 6-DIP (0.300", 7.62mm) |
| Supplier Device Package | 6-DIP |
| Approval Agency | - |
| Grade | - |
| Qualification | - |
| Base Product Number | PVN012 |
| On-State Resistance (Max) | 100 mOhms |
| Product Attribute | |
 |
 |
 |
| Part Number | PVN012PBF | PVN012 | PVN012APBF | PVN012AS-TPBF |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SSR RELAY SPST-NO 2.5A 0-20V | SSR RELAY SPST-NO 2.5A 0-20V | SSR RELAY SPST-NO 4A 0-20V | SSR RELAY SPST-NO 4A 0-20V |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR) |
