Product CatalogPart Number
PYQ75-36WS48
Manufacturer
TDK-LambdaDescription
DC DC CONVERTER 48V 75W
Datasheet
DatasheetPackage
Quarter Brick
In Stock
22,300 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PYQ75-36WS48
PYQ75-36WS48
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 48V 1.56A 9V - 75V Input
Quick Inquiry
PYQ75-36WS48
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | TDK-Lambda |
| Series | PYQ75 (75W) |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.56A |
| Power (Watts) | 75 W |
| Applications | ITE (Commercial), Railway |
| Features | Adjustable Output |
| Operating Temperature | -40°C ~ 105°C (With Derating) |
| Efficiency | 90% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | Quarter Brick |
| Size / Dimension | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) |
| Supplier Device Package | Quarter Brick |
| Control Features | - |
| Approval Agency | - |
| Standard Number | 62368-1 |
| Base Product Number | - |
| Voltage - Isolation | 3 kV |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | PYQ75-36WS12 | PYQ75-36WS15 | PYQ75-36WS24 | PYQ75-36WS28 |
| Manufacturer | TDK-Lambda | TDK-Lambda | TDK-Lambda | TDK-Lambda |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 12V 75W | DC DC CONVERTER 15V 75W | DC DC CONVERTER 24V 75W | DC DC CONVERTER 28V 75W |
| Series | TDK-Lambda | TDK-Lambda | TDK-Lambda | TDK-Lambda |
| Packaging | Tray | Tray | Tray | Tray |
