Product CatalogPart Number
QSVW042A0B41-HZ
Manufacturer
OmniOn Power™Description
DC DC CONVERTER 12V
Datasheet
DatasheetPackage
Quarter Brick
In Stock
17,095 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
QSVW042A0B41-HZ
QSVW042A0B41-HZ
lmages are for reference only.Payment Methods
Delivery Services
Intermediate Bus Converter DC DC Converter 1 Output 12V 42A 36V - 75V Input
Quick Inquiry
QSVW042A0B41-HZ
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | OmniOn Power™ |
| Series | Barracuda™ QSVW042A0B |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Type | Intermediate Bus Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 36V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 42A |
| Power (Watts) | - |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OCP, OTP, OVP, UVLO |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 95% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | Quarter Brick |
| Size / Dimension | 2.30" L x 1.45" W x 0.49" H (58.4mm x 36.8mm x 12.6mm) |
| Supplier Device Package | Quarter Brick |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | QSVW042 |
| Voltage - Isolation | 2.25 kV |
Parts with Similar Specifications
| Product Attribute | |
|
 |
|
| Part Number | QSVW042A0B641-HZ | QSVW042A0B9641-HZ | QSVW035A0B41-HZ | QSVW035A0B41-PZ |
| Manufacturer | OmniOn Power™ | OmniOn Power™ | OmniOn Power™ | OmniOn Power™ |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | RoHS Compliant | RoHS Compliant |
| Description | DC DC CONVERTER 12V | HTTPS://LIBRARY.INDUSTRIALSOLUTI | DC DC CONVERTER 12V 420W | DC DC CONVERTER 12V |
| Series | OmniOn Power™ | OmniOn Power™ | OmniOn Power™ | OmniOn Power™ |
| Packaging | Bulk | Bulk | Tray | Bulk |
