RXv2 RX23E-B Microcontroller IC 32-Bit 32MHz 256KB (256K x 8) FLASH 80-LFQFP (12x12)
R5F523E6NDFN#10
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Renesas Electronics Corporation |
| Series | RX23E-B |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | RXv2 |
| Core Size | 32-Bit |
| Speed | 32MHz |
| Connectivity | CANbus, I2C, SCI, SPI, UART/USART |
| Peripherals | DMA, LCD, LVD, POR, PWM, WDT |
| Number of I/O | 43 |
| Program Memory Size | 256KB (256K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 8K x 8 |
| RAM Size | 32K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Data Converters | A/D 8x12b SAR, 8x24b Sigma-Delta; D/A 1x16b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 80-LFQFP (12x12) |
| Package / Case | 80-LQFP |
| Base Product Number | R5F523 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | R5F523E6NDFN#30 | R5F523E6NDFN#50 | R5F523E6NDBS#00 | R5F523E6NDBS#20 |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 32BIT MCU RX23E-B 256K LFQFP80 T | 32BIT MCU RX23E-B 256K LFQFP80 T | 32BIT MCU RX23E-B 256K LFBGA100 | 32BIT MCU RX23E-B 256K LFBGA100 |
| Series | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Packaging | Tray | Tape & Reel (TR) | Tray | Tray |
