R5F566NNDDBD#20
lmages are for reference only.R5F566NNDDBD#20
IC MCU 32BIT 4MB FLASH 224LFBGA
Datasheet224-LFBGA
48,056 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RXv3 RX600 Microcontroller IC 32-Bit Single-Core 120MHz 4MB (4M x 8) FLASH 224-LFBGA (13x13)
R5F566NNDDBD#20
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Renesas Electronics Corporation |
| Series | RX600 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | RXv3 |
| Core Size | 32-Bit Single-Core |
| Speed | 120MHz |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, MMC/SD, QSPI, SCI, SPI, SSI, USB OTG |
| Peripherals | DMA, LCD, LVD, POR, PWM, WDT |
| Number of I/O | 182 |
| Program Memory Size | 4MB (4M x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 32K x 8 |
| RAM Size | 1M x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 3.6V |
| Data Converters | A/D 8x12b, 21x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 224-LFBGA (13x13) |
| Package / Case | 224-LFBGA |
| Base Product Number | R5F566 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | R5F566NNDDBG#20 | R5F566NNDDFB#10 | R5F566NNDDFB#30 | R5F566NNDDFC#30 |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 32BIT 4MB FLASH 176LFBGA | IC MCU 32BIT 4MB FLASH 144LFQFP | IC MCU 32BIT 4MB FLASH 144LFQFP | IC MCU 32BIT 4MB FLASH 176LFQFP |
| Series | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Packaging | Tray | Tray | Tray | Tray |
