RB6122-16-1M0
Manufacturer
Schaffner EMC Inc.Description
CMC 1MH 16A 2LN TH
Datasheet
DatasheetPackage
Horizontal, 4 PC Pin
In Stock
52,602 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RB6122-16-1M0
RB6122-16-1M0
lmages are for reference only.Payment Methods
Delivery Services
1 mH @ 400 Hz 2 Line Common Mode Choke Through Hole 16A DCR 4.8mOhm (Typ)
Quick Inquiry
RB6122-16-1M0
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Schaffner EMC Inc. |
| Series | RB |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 1 mH @ 400 Hz |
| Current Rating (Max) | 16A |
| DC Resistance (DCR) (Max) | 4.8mOhm (Typ) |
| Voltage Rating - DC | 1000V (1kV) |
| Voltage Rating - AC | 600V |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 2.098" L x 2.020" W (53.29mm x 51.31mm) |
| Height (Max) | 1.634" (41.50mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | RB6122 |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | RB6122-25-0M6 | RB6122-36-0M5 | RB6122-50-0M3 | RB6132-16-0M8 |
| Manufacturer | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 640UH 25A 2LN TH | CMC 450UH 36A 2LN TH | CMC 250UH 50A 2LN TH | CMC 800UH 16A 3LN TH |
| Series | RB | RB | RB | RB |
| Packaging | Bulk | Bulk | Bulk | Bulk |
