RC-2-B
lmages are for reference only.RC-2-B
FIXED IND 3.9MH 320MA 3.9 OHM TH
DatasheetRadial, Vertical Cylinder
83,435 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3.9 mH Unshielded Drum Core, Wirewound Inductor 320 mA 3.9Ohm Radial, Vertical Cylinder
RC-2-B
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Triad Magnetics |
| Series | RC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 3.9 mH |
| Tolerance | ±10% |
| Current Rating (Amps) | 320 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 3.9Ohm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.600" Dia (15.24mm) |
| Height - Seated (Max) | 0.930" (23.62mm) |
| Base Product Number | - |
| Product Attribute | |
 |
 |
|
| Part Number | RC-2-B | RC-1 | RC-10 | RC-10-B |
| Manufacturer | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 3.9MH 320MA 3.9 OHM TH | FIXED IND 5.6MH 250MA 6.1 OHM TH | FIXED IND 100UH 2A 98 MOHM TH | FIXED IND 100UH 2A 98 MOHM TH |
| Series | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
