Product CatalogPart Number
RCLAMP0594P.TAT
Manufacturer
Semtech CorporationDescription
4-LINES 5V 0.3PF ESD SMF2510P8 (
Datasheet
DatasheetPackage
10-UFDFN
In Stock
67,529 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RCLAMP0594P.TAT
RCLAMP0594P.TAT
lmages are for reference only.Payment Methods
Delivery Services
15V Clamp 6A (8/20µs) Ipp Tvs Diode Surface Mount 10-DFN (2.5x1)
Quick Inquiry
RCLAMP0594P.TAT
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Semtech Corporation |
| Series | RailClamp® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Steering (Rail to Rail) |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 15V |
| Current - Peak Pulse (10/1000µs) | 6A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | HDMI |
| Capacitance @ Frequency | 0.8pF @ 1MHz (Max) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 10-UFDFN |
| Supplier Device Package | 10-DFN (2.5x1) |
| Base Product Number | - |
| Unidirectional Channels | 4 |
| Grade | - |
| Qualification | - |
