RN143-0.5-02-100M
lmages are for reference only.RN143-0.5-02-100M
CMC 100MH 500MA 2LN TH
DatasheetHorizontal, 4 PC Pin
22,178 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 500mA DCR 2.9Ohm (Typ)
RN143-0.5-02-100M
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Schaffner EMC Inc. |
| Series | RN |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 100 mH @ 10 kHz |
| Current Rating (Max) | 500mA |
| DC Resistance (DCR) (Max) | 2.9Ohm (Typ) |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 300V |
| Operating Temperature | -40°C ~ 100°C |
| Ratings | - |
| Approval Agency | ENEC, UR, VDE |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 1.303" L x 1.280" W (33.10mm x 32.50mm) |
| Height (Max) | 0.787" (20.00mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | RN143 |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | RN143-0.5-02 | RN204-0.6-02-4M4 | RN116-1.7-02-4M0 | RN204-1.5-02-1M6 |
| Manufacturer | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 100MH 500MA 2LN TH | CMC 4.4MH 600MA 2LN TH | CMC 4MH 1.7A 2LN TH | CMC 1.6MH 1.5A 2LN TH |
| Series | RN | RN | RN | RN |
| Packaging | Tray | Tube | Tube | Tube |
