RP73PF1E86R6BTD
lmages are for reference only.RP73PF1E86R6BTD
RES 86.6 OHM 0.1% 1/10W 0402
Datasheet0402 (1005 Metric)
83,240 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
86.6 Ohms ±0.1% 0.1W, 1/10W Chip Resistor 0402 (1005 Metric) Thin Film
RP73PF1E86R6BTD
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | TE Connectivity Passive Product |
| Series | RP73, Holsworthy |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Resistance | 86.6 Ohms |
| Tolerance | ±0.1% |
| Power (Watts) | 0.1W, 1/10W |
| Composition | Thin Film |
| Features | - |
| Temperature Coefficient | ±25ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | 0402 (1005 Metric) |
| Supplier Device Package | 0402 |
| Ratings | - |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Height - Seated (Max) | 0.014" (0.35mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | RP73PF1E |
| Product Attribute |  |
 |
 |
 |
| Part Number | RP73PF1E86R6BTDF | RP73PF1E806RBTD | RP73PF1E80K6BTD | RP73PF1E80R6BTD |
| Manufacturer | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES 86.6 OHM 0.1% 1/16W 0402 | RES 806 OHM 0.1% 1/10W 0402 | RES 80.6K OHM 0.1% 1/10W 0402 | RES 80.6 OHM 0.1% 1/10W 0402 |
| Series | TE Connectivity Passive Product | TE Connectivity Passive Product | ||
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
