RT8511AGQWA
lmages are for reference only.RT8511AGQWA
IC LED DRVR RGLTR PWM 1.2A 8WDFN
Datasheet8-WDFN Exposed Pad
62,964 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) PWM Dimming 1.2A (Switch) 8-WDFN (3x3)
RT8511AGQWA
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 24V |
| Voltage - Output | 43V |
| Current - Output / Channel | 1.2A (Switch) |
| Frequency | 1MHz |
| Dimming | PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-WDFN Exposed Pad |
| Supplier Device Package | 8-WDFN (3x3) |
| Base Product Number | RT8511 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | RT8510GQW | RT8511AGQW | RT8511BGQW | RT9278GQV |
| Manufacturer | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV RGLTR PWM 40MA 16WQFN | IC LED DRVR RGLTR PWM 1.2A 8WDFN | IC LED DRVR RGLTR PWM 2.2A 8WDFN | IC LED DRIVER RGLTR 2A 10VDFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
