Product CatalogPart Number
RT9048AGQW
Manufacturer
Richtek USA Inc.Description
IC LDO 1.5A LOW DROPOUT WDFN-8
Datasheet
DatasheetPackage
8-WDFN Exposed Pad
In Stock
79,604 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RT9048AGQW
RT9048AGQW
lmages are for reference only.Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 1.5A 8-WDFN (3x3)
Quick Inquiry
RT9048AGQW
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 1.6V |
| Voltage - Output (Min/Fixed) | 0.65V |
| Voltage - Output (Max) | 5.7V |
| Voltage Dropout (Max) | 0.3V @ 1.5A |
| Current - Output | 1.5A |
| Current - Quiescent (Iq) | - |
| PSRR | - |
| Control Features | Enable, Soft Start |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-WDFN Exposed Pad |
| Supplier Device Package | 8-WDFN (3x3) |
| Base Product Number | RT9048 |
| Current - Supply (Max) | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | RT9001-12GG | RT9001-33GG | RT9009GMS5 | RT9010-12GJ6 |
| Manufacturer | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1.2V 600MA SOT223 | IC REG LINEAR 3.3V 600MA SOT223 | IC REG LIN POS ADJ 2.5A TO263S-5 | IC REG LIN 1.2V 300MA TSOT23-6 |
| Series | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
