Product CatalogPart Number
RT9715AGB
Manufacturer
Richtek USA Inc.Description
IC PWR SWITCH N-CHAN 1:1 SOT23-5
Datasheet
DatasheetPackage
SC-74A, SOT-753
In Stock
33,610 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RT9715AGB
RT9715AGB
lmages are for reference only.Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 2A SOT-23-5
Quick Inquiry
RT9715AGB
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | USB Switch |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 2A |
| Rds On (Typ) | 90mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-5 |
| Package / Case | SC-74A, SOT-753 |
| Base Product Number | RT9715 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | RT9715AGBR | RT9715AGF | RT9715AGS | RT9715BGB |
| Manufacturer | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC PWR SWTCH N-CHAN 1:1 SOT23-5R | IC PWR SWITCH N-CHAN 1:1 8MSOP | IC PWR SWITCH N-CHANNEL 1:1 8SOP | IC PWR SWITCH N-CHAN 1:1 SOT23-5 |
| Series | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
