RYA30005
lmages are for reference only.RYA30005
RELAY GEN PURPOSE SPST 8A 5V
Datasheet-
32,233 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole
RYA30005
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | RY, SCHRACK |
| Packaging | Tray |
| RoHS Status | |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 3200VA |
| Coil Current | 44.6 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Fully |
| Coil Insulation | - |
| Must Operate Voltage | 3.5 VDC |
| Must Release Voltage | 0.5 VDC |
| Operate Time | 9 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Approval Agency | cURus, VDE |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 112 Ohms |
| Base Product Number | RYA300 |
| Product Attribute |  |
 |
 |
 |
| Part Number | RYA30006 | RYA30012 | RYA30024 | RY2-2012-26-1012 |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | Altech Corporation |
| RoHS Status | ROHS3 Compliant | |||
| Description | RELAY GEN PURPOSE SPST 8A 6V | RELAY GEN PURPOSE SPST 8A 12V | RELAY GEN PURPOSE SPST 8A 24V | RELAY GEN PURPOSE DPDT 12A 12V |
| Series | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | Altech Corporation |
| Packaging | Tray | Bulk | Bulk | Bulk |
