Product CatalogPart Number
S2M0016120K-1
Manufacturer
SMC Diode SolutionsDescription
MOSFET SILICON CARBIDE SIC 1200V
Datasheet
DatasheetPackage
TO-247-4
In Stock
28,985 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
S2M0016120K-1
S2M0016120K-1
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 1200 V 140A (Tc) 517W (Tc) Through Hole TO-247-4
Quick Inquiry
S2M0016120K-1
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | SMC Diode Solutions |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 140A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 18V, 20V |
| Rds On (Max) @ Id, Vgs | 23mOhm @ 75A, 20V |
| Vgs(th) (Max) @ Id | 3.6V @ 23mA |
| Vgs (Max) | +20V, -5V |
| Input Capacitance (Ciss) (Max) @ Vds | 4540 pF @ 1000 V |
| FET Feature | - |
| Power Dissipation (Max) | 517W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247-4 |
| Package / Case | TO-247-4 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 285 nC @ 20 V |
| Grade | - |
| Qualification | - |
