S9S08AW60E5MFDE
lmages are for reference only.S9S08AW60E5MFDE
IC MCU 8BIT 60KB FLASH 48QFN
Datasheet48-VFQFN Exposed Pad
83,288 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
HCS08 - Microcontroller IC 8-Bit 40MHz 60KB (60K x 8) FLASH 48-QFN (7x7)
S9S08AW60E5MFDE
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Core Processor | HCS08 |
| Core Size | 8-Bit |
| Speed | 40MHz |
| Connectivity | I2C, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Number of I/O | 38 |
| Program Memory Size | 60KB (60K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | A/D 8x10b SAR |
| Oscillator Type | External, Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 48-QFN (7x7) |
| Package / Case | 48-VFQFN Exposed Pad |
| Base Product Number | S9S08 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | S9S08AW60E5MFDE | S9S08AW60E5MFGE | S9S08AW60E5MFGER | S9S08AW60E5MFUE |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC MCU 8BIT 60KB FLASH 48QFN | IC MCU 8BIT 60KB FLASH 44LQFP | IC MCU 8BIT 60KB FLASH 44LQFP | IC MCU 8BIT 60KB FLASH 64QFP |
| Series | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor |
| Packaging | Tray | Tray | Tape & Reel (TR) | Bulk |
