S9S08DV96F2CLL
lmages are for reference only.S9S08DV96F2CLL
MICROCONTROLLER, 8-BIT, HC08/S08
Datasheet100-LQFP
34,372 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
S08 S08 Microcontroller IC 8-Bit 40MHz 96KB (96K x 8) FLASH 100-LQFP (14x14)
S9S08DV96F2CLL
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Freescale Semiconductor |
| Series | S08 |
| Packaging | Bulk |
| RoHS Status | |
| Core Processor | S08 |
| Core Size | 8-Bit |
| Speed | 40MHz |
| Connectivity | CANbus, I2C, LINbus, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Number of I/O | 87 |
| Program Memory Size | 96KB (96K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 4K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | A/D 24x12b |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 100-LQFP (14x14) |
| Package / Case | 100-LQFP |
| Base Product Number | S9S08 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | S9S08DV96F2CLF | S9S08DV96F2CLFR | S9S08DV96F2VLL | S9S08AW16AE0CFT |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Not applicable | ROHS3 Compliant |
| Description | IC MCU 8BIT 96KB FLASH 48LQFP | IC MCU 8BIT 96KB FLASH 48LQFP | IC MCU 8BIT 96KB FLASH 100LQFP | IC MCU 8BIT 16KB FLASH 48QFN |
| Series | NXP USA Inc. | NXP USA Inc. | Freescale Semiconductor | NXP USA Inc. |
| Packaging | Tray | Tape & Reel (TR) | Bulk | Tray |
