S9S12H256J1VFVR
lmages are for reference only.S9S12H256J1VFVR
MCU 16-BIT HCS12 HCS12 CISC 256K
Datasheet144-LQFP
34,920 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
HCS12 - Microcontroller IC 16-Bit 50MHz 256KB (256K x 8) FLASH 144-LQFP (20x20)
S9S12H256J1VFVR
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Freescale Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Core Processor | HCS12 |
| Core Size | 16-Bit |
| Speed | 50MHz |
| Connectivity | CANbus, I2C, IrDA, LINbus, SCI, SPI, UART/USART |
| Peripherals | LCD, LVD, POR, PWM, WDT |
| Number of I/O | 85 |
| Program Memory Size | 256KB (256K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| RAM Size | 6K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.35V ~ 5.25V |
| Data Converters | A/D 8x8/10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 144-LQFP (20x20) |
| Package / Case | 144-LQFP |
| Base Product Number | S9S12 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | S9S12H256J1VFV | S9S12H256J1VPVER | S9S12H256J2VFVER | S9S12B128F0MFUE |
| Manufacturer | Freescale Semiconductor | Freescale Semiconductor | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | RoHS non-compliant | Not applicable | ROHS3 Compliant | ROHS3 Compliant |
| Description | MCU 16 BIT HCS12 HCS12 CISC 256K | MCU 16 BIT HCS12 HCS12 CISC 256K | IC MCU 16BIT 256KB FLASH 144LQFP | IC MCU 16BIT 128KB FLASH 80QFP |
| Series | Freescale Semiconductor | Freescale Semiconductor | NXP USA Inc. | NXP USA Inc. |
| Packaging | Bulk | Bulk | Tape & Reel (TR) | Tray |
