SA39-12EWA
lmages are for reference only.SA39-12EWA
DISPLAY 7SEG 0.39" SGL RED 10DIP
Datasheet10-DIP (0.300", 7.62mm)
31,656 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 7-Segment 1 Character Common Anode 2V 20mA 0.512" H x 0.394" W x 0.276" D (13.00mm x 10.00mm x 7.00mm) 10-DIP (0.300", 7.62mm)
SA39-12EWA
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | Kingbright |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Characters | 1 |
| Size / Dimension | 0.512" H x 0.394" W x 0.276" D (13.00mm x 10.00mm x 7.00mm) |
| Digit/Alpha Size | 0.39" (10.00mm) |
| Display Type | 7-Segment |
| Common Pin | Common Anode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2V |
| Current - Test | 20mA |
| Millicandela Rating | 4.1mcd |
| Wavelength - Peak | 627nm |
| Power Dissipation (Max) | 75mW |
| Package / Case | 10-DIP (0.300", 7.62mm) |
| Base Product Number | SA39-12 |
| Display Format | - |
| Product Attribute | |
 |
|
|
| Part Number | SA39-12CGKWA | SA39-12GWA | SA39-12SRWA | SA39-12SURKWA |
| Manufacturer | Kingbright | Kingbright | Kingbright | Kingbright |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DISPLAY 7SEG 0.39" SGL GRN 10DIP | DISPLAY 7SEG 0.39" SGL GRN 10DIP | DISPLAY 7SEG 0.39" SGL RED 10DIP | DISPLAY 7SEG 0.39" SGL RED 10DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
