SCTWA40N120G2V
Manufacturer
STMicroelectronicsDescription
DISCRETE
Datasheet
DatasheetPackage
TO-247-3
In Stock
33,635 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SCTWA40N120G2V
SCTWA40N120G2V
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 1200 V 36A (Tc) 278W (Tc) Through Hole TO-247 Long Leads
Quick Inquiry
SCTWA40N120G2V
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 36A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 18V |
| Rds On (Max) @ Id, Vgs | 100mOhm @ 20A, 18V |
| Vgs(th) (Max) @ Id | 4.9V @ 1mA |
| Vgs (Max) | +18V, -5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1233 pF @ 800 V |
| FET Feature | - |
| Power Dissipation (Max) | 278W (Tc) |
| Operating Temperature | -55°C ~ 200°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247 Long Leads |
| Package / Case | TO-247-3 |
| Base Product Number | SCTWA40 |
| Gate Charge (Qg) (Max) @ Vgs | 61 nC @ 18 V |
| Grade | - |
| Qualification | - |
