SFH6943A-2T
lmages are for reference only.SFH6943A-2T
OPTOISO 1.768KV 4CH TRANS 10SOT
DatasheetSOT-223-10
11,724 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor Output 1768Vrms 4 Channel 10-SMD
SFH6943A-2T
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 4 |
| Voltage - Isolation | 1768Vrms |
| Current Transfer Ratio (Min) | 63% @ 1mA |
| Current Transfer Ratio (Max) | 200% @ 1mA |
| Turn On / Turn Off Time (Typ) | 2.6µs, 2.8µs |
| Rise / Fall Time (Typ) | 3µs, 3.1µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 70V |
| Current - Output / Channel | 10mA |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Current - DC Forward (If) (Max) | 3 mA |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | SOT-223-10 |
| Supplier Device Package | 10-SMD |
| Base Product Number | SFH6943 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
 |
 |
| Part Number | SFH6943A-3 | SFH6943A-3T | SFH690ABT | SFH690AT |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 1.768KV 4CH TRANS 10SOT | OPTOISO 1.768KV 4CH TRANS 10SOT | OPTOISOLATOR 3.75KV TRANS 4-SOP | OPTOISOLATOR 3.75KV TRANS 4-SOP |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
