Product CatalogPart Number
SHV24-1A85-78D3K
Manufacturer
Standex-Meder ElectronicsDescription
HIGH VOLTAGE REED RELAY, FORM 1A
Datasheet
DatasheetPackage
-
In Stock
39,168 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SHV24-1A85-78D3K
SHV24-1A85-78D3K
lmages are for reference only.Payment Methods
Delivery Services
Quick Inquiry
SHV24-1A85-78D3K
Specifications
| Category | Relays - Reed Relays - |
| Manufacturer | Standex-Meder Electronics |
| Series | SHV |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 1000VAC, 1000VDC - Max |
| Coil Type | Non Latching |
| Features | Diode |
| Termination Style | PC Pin |
| Seal Rating | - |
| Must Operate Voltage | 16.4 VDC |
| Must Release Voltage | 3.6 VDC |
| Operating Temperature | -40°C ~ 105°C |
| Contact Material | - |
| Coil Resistance | 2 kOhms |
| Coil Current | 12 mA |
| Operate Time | 1.1 ms |
| Release Time | 100 µs |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | SHV24-1A85-78D4K | SHV24-1A85-78L3K | SHV24-1A85-78L4K | S1-05-2AD |
| Manufacturer | Standex-Meder Electronics | Standex-Meder Electronics | Standex-Meder Electronics | Sensata-Cynergy3 |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | HIGH VOLTAGE REED RELAY, FORM 1A | HIGH VOLTAGE REED RELAY, FORM 1A | HIGH VOLTAGE REED RELAY, FORM 1A | RELAY REED TWIN N/O 1.5KV 5V |
| Series | SHV | SHV | SHV | S1 |
| Packaging | Tube | Tube | Tube | Bulk |
