SI2300-TP
lmages are for reference only.SI2300-TP
MOSFET N-CH 20V 4.5A SOT23
DatasheetTO-236-3, SC-59, SOT-23-3
90,507 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 20 V 4.5A (Tj) 1W Surface Mount SOT-23
SI2300-TP
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 4.5A (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Rds On (Max) @ Id, Vgs | 25mOhm @ 4.5A, 4.5V |
| Vgs(th) (Max) @ Id | 900mV @ 250µA |
| Vgs (Max) | ±10V |
| Input Capacitance (Ciss) (Max) @ Vds | 482 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | SI2300 |
| Gate Charge (Qg) (Max) @ Vgs | 4.2 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SI2300A | SI2300DS-T1-BE3 | SI2300DS-T1-GE3 | SI2012KL3-TP |
| Manufacturer | UMW | Vishay Siliconix | Vishay Siliconix | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 20V 6A 25MR@4.5V,6A 1V@50A N CHA | N-CHANNEL 30-V (D-S) MOSFET | MOSFET N-CH 30V 3.6A SOT23-3 | P-CHANNEL MOSFET,DFN1006-3 |
| Series | UMW | - | TrenchFET® | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
