SI8642ET-ASR
lmages are for reference only.SI8642ET-ASR
AUTOMOTIVE 10 KV SURGE, 5 KV ISO
Datasheet16-SOIC (0.295", 7.50mm Width)
60,269 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 35kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
SI8642ET-ASR
| Category | Isolators - Digital Isolators - |
| Manufacturer | Skyworks Solutions Inc. |
| Series | Si864x |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Technology | Capacitive Coupling |
| Type | General Purpose |
| Isolated Power | Yes |
| Number of Channels | 4 |
| Inputs - Side 1/Side 2 | 2/2 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 35kV/µs |
| Data Rate | 150Mbps |
| Propagation Delay tpLH / tpHL (Max) | 13ns, 13ns |
| Pulse Width Distortion (Max) | 4.5ns |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Voltage - Supply | 2.375V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | SI8642 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute |  |
 |
|
 |
| Part Number | SI8642ET-AS | SI8642ET-AS2 | SI8642ET-AS2R | SI8642ET-IS |
| Manufacturer | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. |
| RoHS Status | ROHS3 Compliant | |||
| Description | AUTOMOTIVE 10 KV SURGE, 5 KV ISO | LINEAR IC | LINEAR IC | DGTL ISO 5000VRMS 4CH GP 16SOIC |
| Series | Si864x | Si864x | Si864x | Si864x |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tube |
