SID1183K-TL
lmages are for reference only.SID1183K-TL
IC GATE DRV HI/LO SIDE ESOP-R16B
Datasheet16-PowerSOIC (0.350", 8.89mm Width), 15 Leads
35,840 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
High-Side or Low-Side Gate Driver IC Inverting eSOP-R16B
SID1183K-TL
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Power Integrations |
| Series | SCALE™-1 |
| Packaging | Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Driven Configuration | High-Side or Low-Side |
| Channel Type | Single |
| Number of Drivers | 2 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 4.75V ~ 5.25V |
| Logic Voltage - VIL, VIH | 0.5V, 3.3V |
| Current - Peak Output (Source, Sink) | 8A, 48A |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 465ns, 460ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-PowerSOIC (0.350", 8.89mm Width), 15 Leads |
| Supplier Device Package | eSOP-R16B |
| Base Product Number | SID1183 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SID1183K | SN75372PG4 | SI9910DY-T1-E3 | SI823H8CB-IMR |
| Manufacturer | Power Integrations | Texas Instruments | Vishay Siliconix | Econ Connect |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE DRV HI/LO SIDE ESOP-R16B | IC GATE DRVR LOW-SIDE 8DIP | IC GATE DRVR HIGH-SIDE 8SOIC | IC GATE DRVR HI/LOW SIDE 14DFN |
| Series | SCALE™-1 | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tape & Reel (TR) |
