SIHK105N60EF-T1GE3
lmages are for reference only.SIHK105N60EF-T1GE3
E SERIES POWER MOSFET POWERPAK 1
Datasheet8-PowerBSFN
96,612 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 600 V 24A (Tc) 142W (Tc) Surface Mount PowerPAK®10 x 12
SIHK105N60EF-T1GE3
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | EF |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 24A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 105mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 2301 pF @ 100 V |
| FET Feature | - |
| Power Dissipation (Max) | 142W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerPAK®10 x 12 |
| Package / Case | 8-PowerBSFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 51 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SIHK105N60E-T1-GE3 | SIHA100N60E-GE3 | SIHA105N60EF-GE3 | SIHA11N80AE-GE3 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | E SERIES POWER MOSFET WITH FAST | MOSFET N-CH 600V 30A TO220 | MOSFET N-CH 600V 12A TO220 | MOSFET N-CH 800V 8A TO220 |
| Series | EF | E | EF | E |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube | Tube |
