SIL15E-05W3V3-HJ
lmages are for reference only.SIL15E-05W3V3-HJ
DC DC CONVERTER 0.8-3.63V 55W
Datasheet11-SIP Module
55,009 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.63V 15A 3V - 5.5V Input
SIL15E-05W3V3-HJ
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | SIL15E (55W) |
| Packaging | Tray |
| RoHS Status | RoHS Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output 1 | 0.8 ~ 3.63V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 15A |
| Power (Watts) | 55 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, SCP |
| Operating Temperature | -40°C ~ 100°C |
| Efficiency | 94% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole, Right Angle |
| Package / Case | 11-SIP Module |
| Size / Dimension | 2.00" L x 0.50" W x 0.33" H (50.8mm x 12.7mm x 8.4mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | SIL15E |
| Voltage - Isolation | - |
| Product Attribute | |
|
 |
 |
| Part Number | SIL15E-05W3V3-VJ | SIL15E-12W3V3-VJ | SHHN000A3CL41Z | SPA02A-12 |
| Manufacturer | ARTESYN / Advanced Energy | ARTESYN / Advanced Energy | OmniOn Power™ | MEAN WELL USA Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 0.8-3.63V 55W | DC DC CONVERTER 0.8-3.63V 50W | DC DC CONVERTER +/-15V 9W | DC DC CONVERTER 12V 2W |
| Series | ARTESYN / Advanced Energy | ARTESYN / Advanced Energy | OmniOn Power™ | MEAN WELL USA Inc. |
| Packaging | Tray | Tray | Bulk | Tube |
