SIP41109DY-T1-E3
lmages are for reference only.SIP41109DY-T1-E3
IC GATE DRVR HALF-BRIDGE 8SO
Datasheet8-SOIC (0.154", 3.90mm Width)
63,232 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
SIP41109DY-T1-E3
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 10.8V ~ 13.2V |
| Logic Voltage - VIL, VIH | 1V, 4V |
| Current - Peak Output (Source, Sink) | 800mA, 1A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 48 V |
| Rise / Fall Time (Typ) | 45ns, 35ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | SIP41109 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SIP41101DQ-T1-E3 | SIP41103DM-T1-E3 | SIP41104DY-T1-E3 | SIP41111DY-T1-E3 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE DRVR HALF-BRIDGE 16TSSOP | IC GATE DRVR HALF-BRIDG MLP33-10 | IC GATE DRVR HALF-BRIDGE 8SO | IC GATE DRVR HALF-BRIDGE 8SOIC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
