Product CatalogPart Number
SIR820DP-T1-GE3
Manufacturer
Vishay SiliconixDescription
MOSFET N-CH 30V 40A PPAK SO-8
Datasheet
DatasheetPackage
PowerPAK® SO-8
In Stock
63,039 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SIR820DP-T1-GE3
SIR820DP-T1-GE3
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 40A (Tc) 37.8W (Tc) Surface Mount PowerPAK® SO-8
Quick Inquiry
SIR820DP-T1-GE3
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2.4V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3512 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 37.8W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerPAK® SO-8 |
| Package / Case | PowerPAK® SO-8 |
| Base Product Number | SIR820 |
| Gate Charge (Qg) (Max) @ Vgs | 95 nC @ 10 V |
| Grade | - |
| Qualification | - |
